Game 1 Unit 15 of 64 1 hr learning time
Results Screen
Proper end-of-game display with final scores, winner announcement, and victory margin.
23% of Ink War
When a game ends, the current display simply shows “P1 WINS!” or “DRAW!” overlaid on the board. This unit creates a proper results screen with structured information: a header, final scores for both players in their colours, the winner announcement, and the victory margin.
The results screen transforms the end of game from an afterthought into a satisfying conclusion.
Run It
pasmonext --sna inkwar.asm inkwar.sna
Play a complete game to see the enhanced results screen with final scores and victory margin.
Results Screen Layout
The screen shows information in a clear hierarchy:
GAME OVER
P1:32 P2:32
P1 WINS!
BY 04 CELLS
PRESS ANY KEYEach element has a defined position:
; Results screen positions
GAMEOVER_ROW equ 18 ; "GAME OVER" header
GAMEOVER_COL equ 11 ; (32-9)/2 = 11.5
FINAL_ROW equ 20 ; Final score row
FINAL_P1_COL equ 8 ; "P1: nn"
FINAL_P2_COL equ 20 ; "P2: nn"
WINNER_ROW equ 22 ; Winner announcement
WINNER_COL equ 10 ; Centred
MARGIN_ROW equ 23 ; "BY nn CELLS"
MARGIN_COL equ 11
; Messages for results screen
msg_gameover: defb "GAME OVER", 0
msg_final: defb "FINAL SCORE", 0
msg_by: defb "BY ", 0
msg_cells: defb " CELLS", 0
The layout uses the lower portion of the screen, below the game board.
Enhanced Show Results
The show_results function now builds the complete results display:
show_results:
; Display "GAME OVER" header
ld b, GAMEOVER_ROW
ld c, GAMEOVER_COL
ld hl, msg_gameover
ld e, TEXT_ATTR
call print_message
; Display final P1 score with colour
ld b, FINAL_ROW
ld c, FINAL_P1_COL
; ... print "P1:" and score ...
ld e, P1_TEXT
call set_attr_range
; Display final P2 score with colour
; ... same pattern for P2 ...
; Determine winner and display message
ld a, (p1_count)
ld b, a
ld a, (p2_count)
cp b
jr c, .sr_p1_wins
jr z, .sr_draw
jr .sr_p2_wins
.sr_p1_wins:
ld hl, msg_p1_wins
ld e, P1_TEXT
call print_message
; Calculate margin: p1 - p2
call show_margin
jr .sr_prompt
; ... similar for P2 wins and draw ...
.sr_prompt:
ld hl, msg_continue
call print_message
ret
Key improvements:
- “GAME OVER” header — Clear signal the game has ended
- Final scores — Both players’ scores displayed prominently with their colours
- Winner message — In the winner’s colour (P1 = red, P2 = blue)
- Victory margin — How many cells the winner led by
Calculating Victory Margin
When someone wins, we show the score difference:
; ----------------------------------------------------------------------------
; Show Margin
; ----------------------------------------------------------------------------
; Displays "BY nn CELLS" for victory margin
; A = margin (difference in scores)
show_margin:
push af ; Save margin
; Print "BY "
ld b, MARGIN_ROW
ld c, MARGIN_COL
ld hl, msg_by
ld e, TEXT_ATTR
call print_message
; Print margin number
ld c, MARGIN_COL + 3
pop af
call print_two_digits
; Print " CELLS"
ld c, MARGIN_COL + 5
ld hl, msg_cells
call print_message
ret
The margin calculation uses neg to negate one score before adding:
ld a, (p1_count)
ld b, a
ld a, (p2_count)
neg ; A = -p2_count
add a, b ; A = p1_count - p2_countThis gives the difference without needing a subtraction instruction.
Draw Handling
Draws skip the margin display entirely — there’s no meaningful difference to show:
.sr_draw:
; Display "DRAW!" (centred)
ld b, WINNER_ROW
ld c, WINNER_COL + 2
ld hl, msg_draw
ld e, TEXT_ATTR
call print_message
; No margin for draw - skip directly to promptThe DRAW! message is centred differently (offset by 2) because it’s shorter than “P1 WINS!”.
Visual Consistency
The results screen maintains visual consistency with the rest of the game:
- P1’s score uses
P1_TEXTattribute (red background) - P2’s score uses
P2_TEXTattribute (blue background) - Winner message uses the winner’s colour
- Header and margin use neutral
TEXT_ATTR
This colour coding reinforces the game’s visual language — players immediately recognise “their” colour.
The Complete Code
; ============================================================================
; INK WAR - Unit 15: Results Screen
; ============================================================================
; Proper end-of-game display with final scores, winner announcement,
; and score difference. Clear presentation of the game outcome.
;
; Controls: Q=Up, A=Down, O=Left, P=Right, SPACE=Claim
; 1=Two Player, 2=AI Easy, 3=AI Medium, 4=AI Hard
; ============================================================================
org 32768
; ----------------------------------------------------------------------------
; Constants
; ----------------------------------------------------------------------------
ATTR_BASE equ $5800
DISPLAY_FILE equ $4000
CHAR_SET equ $3C00 ; ROM character set base address
BOARD_ROW equ 8
BOARD_COL equ 12
BOARD_SIZE equ 8
; Display positions
SCORE_ROW equ 2 ; Score display row
P1_SCORE_COL equ 10 ; "P1: nn" column
P2_SCORE_COL equ 18 ; "P2: nn" column
TURN_ROW equ 4 ; Turn indicator row
TURN_COL equ 14 ; Turn indicator column
RESULT_ROW equ 20 ; Winner message row
RESULT_COL equ 11 ; Winner message column
; Game constants
TOTAL_CELLS equ 64 ; 8x8 board
; Customised colours (from Unit 3)
EMPTY_ATTR equ %01101000 ; Cyan paper + BRIGHT
BORDER_ATTR equ %01110000 ; Yellow paper + BRIGHT
CURSOR_ATTR equ %01111000 ; White paper + BRIGHT
P1_ATTR equ %01010000 ; Red paper + BRIGHT
P2_ATTR equ %01001000 ; Blue paper + BRIGHT
P1_CURSOR equ %01111010 ; White paper + Red ink + BRIGHT
P2_CURSOR equ %01111001 ; White paper + Blue ink + BRIGHT
; Text display attributes
TEXT_ATTR equ %00111000 ; White paper, black ink
P1_TEXT equ %01010111 ; Red paper, white ink + BRIGHT
P2_TEXT equ %01001111 ; Blue paper, white ink + BRIGHT
P1_BORDER equ 2
P2_BORDER equ 1
ERROR_BORDER equ 2 ; Red border for errors
; Keyboard ports
KEY_PORT equ $fe
ROW_QAOP equ $fb
ROW_ASDF equ $fd
ROW_YUIOP equ $df
ROW_SPACE equ $7f
; Cell states
STATE_EMPTY equ 0
STATE_P1 equ 1
STATE_P2 equ 2
; Game states (state machine)
GS_TITLE equ 0
GS_PLAYING equ 1
GS_RESULTS equ 2
; Game modes
GM_TWO_PLAYER equ 0
GM_VS_AI equ 1
; AI difficulty levels
AI_EASY equ 0 ; Random moves
AI_MEDIUM equ 1 ; Adjacent priority only
AI_HARD equ 2 ; Full strategy (defense + position)
; AI timing
AI_DELAY equ 25 ; Frames before AI moves (~0.5 sec)
; Title screen positions
TITLE_ROW equ 6
TITLE_COL equ 12 ; "INK WAR" (7 chars) centred
MODE1_ROW equ 12 ; "1 - TWO PLAYER"
MODE1_COL equ 9
MODE2_ROW equ 14 ; "2 - AI EASY"
MODE2_COL equ 10
MODE3_ROW equ 16 ; "3 - AI MEDIUM"
MODE3_COL equ 9
MODE4_ROW equ 18 ; "4 - AI HARD"
MODE4_COL equ 10
; Results screen positions
GAMEOVER_ROW equ 18 ; "GAME OVER" header
GAMEOVER_COL equ 11 ; (32-9)/2 = 11.5
FINAL_ROW equ 20 ; Final score row
FINAL_P1_COL equ 8 ; "P1: nn"
FINAL_P2_COL equ 20 ; "P2: nn"
WINNER_ROW equ 22 ; Winner announcement
WINNER_COL equ 10 ; Centred
MARGIN_ROW equ 23 ; "BY nn CELLS"
MARGIN_COL equ 11
CONTINUE_ROW equ 22 ; "PRESS ANY KEY" after results
CONTINUE_COL equ 9 ; (32-13)/2 = 9.5
; Input timing
KEY_DELAY equ 8 ; Frames between key repeats
; ----------------------------------------------------------------------------
; Entry Point
; ----------------------------------------------------------------------------
start:
; Start at title screen
ld a, GS_TITLE
ld (game_state), a
call init_screen
call draw_title_screen
; Black border for title
xor a
out (KEY_PORT), a
main_loop:
halt
; Dispatch based on game state
ld a, (game_state)
or a
jr z, state_title ; GS_TITLE = 0
cp GS_PLAYING
jr z, state_playing
; Must be GS_RESULTS - handled inline after game over
jp main_loop
; ----------------------------------------------------------------------------
; State: Title
; ----------------------------------------------------------------------------
; Waits for 1 (Two Player), 2 (AI Easy), 3 (AI Medium), 4 (AI Hard)
ROW_12345 equ $f7 ; Keyboard row for 1,2,3,4,5
state_title:
; Read keyboard row for keys 1-5
ld a, ROW_12345
in a, (KEY_PORT)
; Check for key 1 (Two Player)
bit 0, a ; Key 1
jr z, .st_two_player
; Check for key 2 (AI Easy)
bit 1, a ; Key 2
jr z, .st_ai_easy
; Check for key 3 (AI Medium)
bit 2, a ; Key 3
jr z, .st_ai_medium
; Check for key 4 (AI Hard)
bit 3, a ; Key 4
jr z, .st_ai_hard
jp main_loop ; No valid key - keep waiting
.st_two_player:
call sound_select
xor a ; GM_TWO_PLAYER = 0
ld (game_mode), a
call start_game
jp main_loop
.st_ai_easy:
call sound_select
ld a, GM_VS_AI
ld (game_mode), a
ld a, AI_EASY
ld (ai_difficulty), a
call start_game
jp main_loop
.st_ai_medium:
call sound_select
ld a, GM_VS_AI
ld (game_mode), a
ld a, AI_MEDIUM
ld (ai_difficulty), a
call start_game
jp main_loop
.st_ai_hard:
call sound_select
ld a, GM_VS_AI
ld (game_mode), a
ld a, AI_HARD
ld (ai_difficulty), a
call start_game
jp main_loop
; ----------------------------------------------------------------------------
; State: Playing
; ----------------------------------------------------------------------------
state_playing:
; Check if AI's turn (Player 2 in vs AI mode)
ld a, (game_mode)
or a
jr z, .sp_human ; Two player mode - human controls
; vs AI mode - check if Player 2's turn
ld a, (current_player)
cp 2
jr z, .sp_ai_turn
.sp_human:
; Human player's turn
call read_keyboard
call handle_input
jp main_loop
.sp_ai_turn:
; AI's turn - use delay counter
ld a, (ai_timer)
or a
jr z, .sp_ai_move ; Timer expired, make move
; Still waiting
dec a
ld (ai_timer), a
jp main_loop
.sp_ai_move:
; Reset timer for next AI turn
ld a, AI_DELAY
ld (ai_timer), a
; AI makes a move
call ai_make_move
jp main_loop
; ----------------------------------------------------------------------------
; Start Game
; ----------------------------------------------------------------------------
; Transitions from title to playing state
start_game:
ld a, GS_PLAYING
ld (game_state), a
call init_screen
call init_game
call draw_board_border
call draw_board
call draw_ui
call draw_cursor
call update_border
; Wait for key release before playing
call wait_key_release
ret
; ----------------------------------------------------------------------------
; Initialise Screen
; ----------------------------------------------------------------------------
init_screen:
xor a
out (KEY_PORT), a
; Clear display file (pixels)
ld hl, DISPLAY_FILE
ld de, DISPLAY_FILE+1
ld bc, 6143
ld (hl), 0
ldir
; Clear all attributes to white paper, black ink
ld hl, ATTR_BASE
ld de, ATTR_BASE+1
ld bc, 767
ld (hl), TEXT_ATTR ; White background for text areas
ldir
ret
; ----------------------------------------------------------------------------
; Draw UI
; ----------------------------------------------------------------------------
; Draws score display and turn indicator
draw_ui:
call draw_scores
call draw_turn_indicator
ret
; ----------------------------------------------------------------------------
; Draw Scores
; ----------------------------------------------------------------------------
; Displays "P1: nn P2: nn" with player colours
draw_scores:
; Count cells for each player
call count_cells
; Draw P1 label "P1:"
ld b, SCORE_ROW
ld c, P1_SCORE_COL
ld a, 'P'
call print_char
inc c
ld a, '1'
call print_char
inc c
ld a, ':'
call print_char
inc c
; Print P1 score
ld a, (p1_count)
call print_two_digits
; Set P1 colour attribute
ld a, SCORE_ROW
ld c, P1_SCORE_COL
ld b, 5 ; "P1:nn" = 5 characters
ld e, P1_TEXT
call set_attr_range
; Draw P2 label "P2:"
ld b, SCORE_ROW
ld c, P2_SCORE_COL
ld a, 'P'
call print_char
inc c
ld a, '2'
call print_char
inc c
ld a, ':'
call print_char
inc c
; Print P2 score
ld a, (p2_count)
call print_two_digits
; Set P2 colour attribute
ld a, SCORE_ROW
ld c, P2_SCORE_COL
ld b, 5
ld e, P2_TEXT
call set_attr_range
ret
; ----------------------------------------------------------------------------
; Draw Turn Indicator
; ----------------------------------------------------------------------------
; Shows "TURN" with current player's colour
draw_turn_indicator:
; Print "TURN"
ld b, TURN_ROW
ld c, TURN_COL
ld a, 'T'
call print_char
inc c
ld a, 'U'
call print_char
inc c
ld a, 'R'
call print_char
inc c
ld a, 'N'
call print_char
; Set attribute based on current player
ld a, (current_player)
cp 1
jr z, .dti_p1
ld e, P2_TEXT
jr .dti_set
.dti_p1:
ld e, P1_TEXT
.dti_set:
ld a, TURN_ROW
ld c, TURN_COL
ld b, 4 ; "TURN" = 4 chars
call set_attr_range
ret
; ----------------------------------------------------------------------------
; Print Character
; ----------------------------------------------------------------------------
; A = ASCII character (32-127), B = row (0-23), C = column (0-31)
; Writes character directly to display file using ROM character set
print_char:
push bc
push de
push hl
push af
; Calculate character data address: CHAR_SET + char*8
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl ; HL = char * 8
ld de, CHAR_SET
add hl, de ; HL = source address
push hl ; Save character data address
; Calculate display file address
; Screen address: high byte varies with row, low byte = column
ld a, b ; A = row (0-23)
and %00011000 ; Get which third (0, 8, 16)
add a, $40 ; Add display file base high byte
ld d, a
ld a, b ; A = row
and %00000111 ; Get line within character row
rrca
rrca
rrca ; Shift to bits 5-7
add a, c ; Add column
ld e, a ; DE = screen address
pop hl ; HL = character data
; Copy 8 bytes (8 pixel rows of character)
ld b, 8
.pc_loop:
ld a, (hl)
ld (de), a
inc hl
inc d ; Next screen line (add 256)
djnz .pc_loop
pop af
pop hl
pop de
pop bc
ret
; ----------------------------------------------------------------------------
; Print Two Digits
; ----------------------------------------------------------------------------
; A = number (0-99), B = row, C = column (will advance by 2)
; Prints number as two digits
print_two_digits:
push bc
; Calculate tens digit
ld d, 0 ; Tens counter
.ptd_tens:
cp 10
jr c, .ptd_print
sub 10
inc d
jr .ptd_tens
.ptd_print:
push af ; Save units digit
; Print tens digit
ld a, d
add a, '0'
call print_char
inc c
; Print units digit
pop af
add a, '0'
call print_char
inc c
pop bc
ret
; ----------------------------------------------------------------------------
; Count Cells
; ----------------------------------------------------------------------------
; Counts cells owned by each player
count_cells:
xor a
ld (p1_count), a
ld (p2_count), a
ld hl, board_state
ld b, 64 ; 64 cells
.cc_loop:
ld a, (hl)
cp STATE_P1
jr nz, .cc_not_p1
ld a, (p1_count)
inc a
ld (p1_count), a
jr .cc_next
.cc_not_p1:
cp STATE_P2
jr nz, .cc_next
ld a, (p2_count)
inc a
ld (p2_count), a
.cc_next:
inc hl
djnz .cc_loop
ret
; ----------------------------------------------------------------------------
; Set Attribute Range
; ----------------------------------------------------------------------------
; A = row, C = start column, B = count, E = attribute
set_attr_range:
push bc
push de
; Calculate start address: ATTR_BASE + row*32 + col
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl
add hl, hl
add hl, hl ; HL = row * 32
ld a, c
add a, l
ld l, a
ld bc, ATTR_BASE
add hl, bc ; HL = attribute address
pop de ; E = attribute
pop bc ; B = count
.sar_loop:
ld (hl), e
inc hl
djnz .sar_loop
ret
; ----------------------------------------------------------------------------
; Update Border
; ----------------------------------------------------------------------------
update_border:
ld a, (current_player)
cp 1
jr z, .ub_p1
ld a, P2_BORDER
jr .ub_set
.ub_p1:
ld a, P1_BORDER
.ub_set:
out (KEY_PORT), a
ret
; ----------------------------------------------------------------------------
; Initialise Game State
; ----------------------------------------------------------------------------
init_game:
ld hl, board_state
ld b, 64
xor a
.ig_loop:
ld (hl), a
inc hl
djnz .ig_loop
ld a, 1
ld (current_player), a
xor a
ld (cursor_row), a
ld (cursor_col), a
ld (p1_count), a
ld (p2_count), a
ld (last_key), a ; No previous key
ld (key_timer), a ; No delay active
; Initialize AI timer
ld a, AI_DELAY
ld (ai_timer), a
ret
; ----------------------------------------------------------------------------
; Draw Board Border
; ----------------------------------------------------------------------------
draw_board_border:
ld c, BOARD_ROW-1
ld d, BOARD_COL-1
ld b, BOARD_SIZE+2
call draw_border_row
ld c, BOARD_ROW+BOARD_SIZE
ld d, BOARD_COL-1
ld b, BOARD_SIZE+2
call draw_border_row
ld c, BOARD_ROW
ld d, BOARD_COL-1
ld b, BOARD_SIZE
call draw_border_col
ld c, BOARD_ROW
ld d, BOARD_COL+BOARD_SIZE
ld b, BOARD_SIZE
call draw_border_col
ret
draw_border_row:
push bc
.dbr_loop:
push bc
push de
ld a, c
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl
add hl, hl
add hl, hl
ld a, d
add a, l
ld l, a
ld bc, ATTR_BASE
add hl, bc
ld (hl), BORDER_ATTR
pop de
pop bc
inc d
djnz .dbr_loop
pop bc
ret
draw_border_col:
push bc
.dbc_loop:
push bc
push de
ld a, c
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl
add hl, hl
add hl, hl
ld a, d
add a, l
ld l, a
ld bc, ATTR_BASE
add hl, bc
ld (hl), BORDER_ATTR
pop de
pop bc
inc c
djnz .dbc_loop
pop bc
ret
; ----------------------------------------------------------------------------
; Draw Board
; ----------------------------------------------------------------------------
draw_board:
ld b, BOARD_SIZE
ld c, BOARD_ROW
.db_row:
push bc
ld b, BOARD_SIZE
ld d, BOARD_COL
.db_col:
push bc
ld a, c
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl
add hl, hl
add hl, hl
ld a, d
add a, l
ld l, a
ld bc, ATTR_BASE
add hl, bc
ld (hl), EMPTY_ATTR
pop bc
inc d
djnz .db_col
pop bc
inc c
djnz .db_row
ret
; ----------------------------------------------------------------------------
; Draw Cursor
; ----------------------------------------------------------------------------
draw_cursor:
call get_cell_state
cp STATE_P1
jr z, .dc_p1
cp STATE_P2
jr z, .dc_p2
ld a, CURSOR_ATTR
jr .dc_set
.dc_p1:
ld a, P1_CURSOR
jr .dc_set
.dc_p2:
ld a, P2_CURSOR
.dc_set:
push af
ld a, (cursor_row)
add a, BOARD_ROW
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl
add hl, hl
add hl, hl
ld a, (cursor_col)
add a, BOARD_COL
add a, l
ld l, a
ld bc, ATTR_BASE
add hl, bc
pop af
ld (hl), a
ret
; ----------------------------------------------------------------------------
; Clear Cursor
; ----------------------------------------------------------------------------
clear_cursor:
call get_cell_state
cp STATE_P1
jr z, .clc_p1
cp STATE_P2
jr z, .clc_p2
ld a, EMPTY_ATTR
jr .clc_set
.clc_p1:
ld a, P1_ATTR
jr .clc_set
.clc_p2:
ld a, P2_ATTR
.clc_set:
push af
ld a, (cursor_row)
add a, BOARD_ROW
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl
add hl, hl
add hl, hl
ld a, (cursor_col)
add a, BOARD_COL
add a, l
ld l, a
ld bc, ATTR_BASE
add hl, bc
pop af
ld (hl), a
ret
; ----------------------------------------------------------------------------
; Get Cell State
; ----------------------------------------------------------------------------
get_cell_state:
ld a, (cursor_row)
add a, a
add a, a
add a, a
ld hl, board_state
ld b, 0
ld c, a
add hl, bc
ld a, (cursor_col)
ld c, a
add hl, bc
ld a, (hl)
ret
; ----------------------------------------------------------------------------
; Read Keyboard
; ----------------------------------------------------------------------------
read_keyboard:
xor a
ld (key_pressed), a
ld a, ROW_QAOP
in a, (KEY_PORT)
bit 0, a
jr nz, .rk_not_q
ld a, 1
ld (key_pressed), a
ret
.rk_not_q:
ld a, ROW_ASDF
in a, (KEY_PORT)
bit 0, a
jr nz, .rk_not_a
ld a, 2
ld (key_pressed), a
ret
.rk_not_a:
ld a, ROW_YUIOP
in a, (KEY_PORT)
bit 1, a
jr nz, .rk_not_o
ld a, 3
ld (key_pressed), a
ret
.rk_not_o:
ld a, ROW_YUIOP
in a, (KEY_PORT)
bit 0, a
jr nz, .rk_not_p
ld a, 4
ld (key_pressed), a
ret
.rk_not_p:
ld a, ROW_SPACE
in a, (KEY_PORT)
bit 0, a
jr nz, .rk_not_space
ld a, 5
ld (key_pressed), a
.rk_not_space:
ret
; ----------------------------------------------------------------------------
; Handle Input
; ----------------------------------------------------------------------------
; Implements key repeat delay for smooth cursor movement
handle_input:
ld a, (key_pressed)
or a
jr nz, .hi_have_key
; No key pressed - reset tracking
xor a
ld (last_key), a
ld (key_timer), a
ret
.hi_have_key:
; Space (claim) always works immediately
cp 5
jr z, try_claim
; Check if same key as last frame
ld b, a ; Save current key
ld a, (last_key)
cp b
jr nz, .hi_new_key
; Same key - check timer
ld a, (key_timer)
or a
jr z, .hi_allow ; Timer expired, allow repeat
dec a
ld (key_timer), a
ret ; Still waiting
.hi_new_key:
; New key pressed - save it and reset timer
ld a, b
ld (last_key), a
ld a, KEY_DELAY
ld (key_timer), a
.hi_allow:
; Process movement
call clear_cursor
ld a, (key_pressed)
cp 1
jr nz, .hi_not_up
ld a, (cursor_row)
or a
jr z, .hi_done
dec a
ld (cursor_row), a
jr .hi_done
.hi_not_up:
cp 2
jr nz, .hi_not_down
ld a, (cursor_row)
cp BOARD_SIZE-1
jr z, .hi_done
inc a
ld (cursor_row), a
jr .hi_done
.hi_not_down:
cp 3
jr nz, .hi_not_left
ld a, (cursor_col)
or a
jr z, .hi_done
dec a
ld (cursor_col), a
jr .hi_done
.hi_not_left:
cp 4
jr nz, .hi_done
ld a, (cursor_col)
cp BOARD_SIZE-1
jr z, .hi_done
inc a
ld (cursor_col), a
.hi_done:
call draw_cursor
ret
; ----------------------------------------------------------------------------
; Try Claim Cell
; ----------------------------------------------------------------------------
try_claim:
call get_cell_state
or a
jr z, .tc_valid
; Cell already claimed - error feedback
call sound_error
call flash_border_error
call update_border ; Restore correct border colour
ret
.tc_valid:
; Valid move - claim the cell
call claim_cell
call sound_claim
ld a, (current_player)
xor 3
ld (current_player), a
call draw_ui ; Update scores and turn indicator
; Check if game is over
call check_game_over
or a
jr z, .tc_continue
; Game over - play appropriate sound and show results
call play_result_sound
call show_results
call victory_celebration
call wait_for_key
; Return to title screen
ld a, GS_TITLE
ld (game_state), a
call init_screen
call draw_title_screen
xor a
out (KEY_PORT), a ; Black border for title
ret
.tc_continue:
call update_border
call draw_cursor
ret
; ----------------------------------------------------------------------------
; Claim Cell
; ----------------------------------------------------------------------------
claim_cell:
ld a, (cursor_row)
add a, a
add a, a
add a, a
ld hl, board_state
ld b, 0
ld c, a
add hl, bc
ld a, (cursor_col)
ld c, a
add hl, bc
ld a, (current_player)
ld (hl), a
push af
ld a, (cursor_row)
add a, BOARD_ROW
ld l, a
ld h, 0
add hl, hl
add hl, hl
add hl, hl
add hl, hl
add hl, hl
ld a, (cursor_col)
add a, BOARD_COL
add a, l
ld l, a
ld bc, ATTR_BASE
add hl, bc
pop af
cp 1
jr z, .clm_is_p1
ld (hl), P2_ATTR
ret
.clm_is_p1:
ld (hl), P1_ATTR
ret
; ----------------------------------------------------------------------------
; Sound - Claim
; ----------------------------------------------------------------------------
sound_claim:
ld hl, 400
ld b, 20
.scl_loop:
push bc
push hl
ld b, h
ld c, l
.scl_tone:
ld a, $10
out (KEY_PORT), a
call .scl_delay
xor a
out (KEY_PORT), a
call .scl_delay
dec bc
ld a, b
or c
jr nz, .scl_tone
pop hl
pop bc
ld de, 20
or a
sbc hl, de
djnz .scl_loop
ret
.scl_delay:
push bc
ld b, 5
.scl_delay_loop:
djnz .scl_delay_loop
pop bc
ret
; ----------------------------------------------------------------------------
; Sound - Error
; ----------------------------------------------------------------------------
; Harsh buzz for invalid move
sound_error:
ld b, 30 ; Duration
.se_loop:
push bc
; Low frequency buzz (longer delay = lower pitch)
ld a, $10
out (KEY_PORT), a
ld c, 80 ; Longer delay for low pitch
.se_delay1:
dec c
jr nz, .se_delay1
xor a
out (KEY_PORT), a
ld c, 80
.se_delay2:
dec c
jr nz, .se_delay2
pop bc
djnz .se_loop
ret
; ----------------------------------------------------------------------------
; Sound - Menu Select
; ----------------------------------------------------------------------------
; Quick high beep for menu selection
sound_select:
ld b, 15 ; Short duration
.ss_loop:
push bc
ld a, $10
out (KEY_PORT), a
ld c, 20 ; High pitch (short delay)
.ss_delay1:
dec c
jr nz, .ss_delay1
xor a
out (KEY_PORT), a
ld c, 20
.ss_delay2:
dec c
jr nz, .ss_delay2
pop bc
djnz .ss_loop
ret
; ----------------------------------------------------------------------------
; Sound - Turn Change
; ----------------------------------------------------------------------------
; Brief descending tone when turn switches
sound_turn:
ld hl, 30 ; Starting pitch (high)
ld b, 8 ; Number of steps
.st_loop:
push bc
push hl
; Play tone at current pitch
ld b, 6 ; Cycles per pitch
.st_tone:
push bc
ld a, $10
out (KEY_PORT), a
ld b, l ; Delay = pitch
.st_d1: djnz .st_d1
xor a
out (KEY_PORT), a
ld b, l
.st_d2: djnz .st_d2
pop bc
djnz .st_tone
pop hl
pop bc
; Increase delay (lower pitch)
ld de, 8
add hl, de
djnz .st_loop
ret
; ----------------------------------------------------------------------------
; Sound - Victory
; ----------------------------------------------------------------------------
; Triumphant ascending fanfare
sound_victory:
; Play three ascending notes
ld hl, 60 ; Starting pitch (low)
ld b, 3 ; Three notes
.sv_note:
push bc
push hl
; Play note
ld b, 25 ; Note duration
.sv_tone:
push bc
ld a, $10
out (KEY_PORT), a
ld b, l
.sv_d1: djnz .sv_d1
xor a
out (KEY_PORT), a
ld b, l
.sv_d2: djnz .sv_d2
pop bc
djnz .sv_tone
pop hl
pop bc
; Decrease delay (higher pitch) for next note
ld a, l
sub 15
ld l, a
; Brief pause between notes
push bc
ld bc, 2000
.sv_pause: dec bc
ld a, b
or c
jr nz, .sv_pause
pop bc
djnz .sv_note
ret
; ----------------------------------------------------------------------------
; Sound - Draw
; ----------------------------------------------------------------------------
; Neutral two-tone sound for draw
sound_draw:
; First tone (mid pitch)
ld b, 20
.sd_tone1:
push bc
ld a, $10
out (KEY_PORT), a
ld c, 40
.sd_d1: dec c
jr nz, .sd_d1
xor a
out (KEY_PORT), a
ld c, 40
.sd_d2: dec c
jr nz, .sd_d2
pop bc
djnz .sd_tone1
; Brief pause
ld bc, 1500
.sd_pause: dec bc
ld a, b
or c
jr nz, .sd_pause
; Second tone (same pitch - neutral)
ld b, 20
.sd_tone2:
push bc
ld a, $10
out (KEY_PORT), a
ld c, 40
.sd_d3: dec c
jr nz, .sd_d3
xor a
out (KEY_PORT), a
ld c, 40
.sd_d4: dec c
jr nz, .sd_d4
pop bc
djnz .sd_tone2
ret
; ----------------------------------------------------------------------------
; Play Result Sound
; ----------------------------------------------------------------------------
; Plays victory or draw sound based on game result
play_result_sound:
; Compare scores
ld a, (p1_count)
ld b, a
ld a, (p2_count)
cp b
jr z, .prs_draw ; Equal = draw
; Someone won - play victory
call sound_victory
ret
.prs_draw:
call sound_draw
ret
; ----------------------------------------------------------------------------
; Flash Border Error
; ----------------------------------------------------------------------------
; Flash border red briefly to indicate error
flash_border_error:
; Flash red 3 times
ld b, 3
.fbe_loop:
push bc
; Red border
ld a, ERROR_BORDER
out (KEY_PORT), a
; Short delay (about 3 frames)
ld bc, 8000
.fbe_delay1:
dec bc
ld a, b
or c
jr nz, .fbe_delay1
; Black border (brief off)
xor a
out (KEY_PORT), a
; Short delay
ld bc, 4000
.fbe_delay2:
dec bc
ld a, b
or c
jr nz, .fbe_delay2
pop bc
djnz .fbe_loop
ret
; ----------------------------------------------------------------------------
; Check Game Over
; ----------------------------------------------------------------------------
; Returns A=1 if game is over (board full), A=0 otherwise
check_game_over:
; Game is over when p1_count + p2_count == 64
ld a, (p1_count)
ld b, a
ld a, (p2_count)
add a, b
cp TOTAL_CELLS
jr z, .cgo_over
xor a ; Not over
ret
.cgo_over:
ld a, 1 ; Game over
ret
; ----------------------------------------------------------------------------
; Show Results
; ----------------------------------------------------------------------------
; Displays enhanced results screen with final scores and winner
show_results:
; Clear turn indicator
ld a, TURN_ROW
ld c, TURN_COL
ld b, 4
ld e, TEXT_ATTR
call set_attr_range
; Display "GAME OVER" header
ld b, GAMEOVER_ROW
ld c, GAMEOVER_COL
ld hl, msg_gameover
ld e, TEXT_ATTR
call print_message
; Display final P1 score
ld b, FINAL_ROW
ld c, FINAL_P1_COL
ld a, 'P'
call print_char
inc c
ld a, '1'
call print_char
inc c
ld a, ':'
call print_char
inc c
ld a, (p1_count)
call print_two_digits
; Set P1 colour
ld a, FINAL_ROW
ld c, FINAL_P1_COL
ld b, 5
ld e, P1_TEXT
call set_attr_range
; Display final P2 score
ld b, FINAL_ROW
ld c, FINAL_P2_COL
ld a, 'P'
call print_char
inc c
ld a, '2'
call print_char
inc c
ld a, ':'
call print_char
inc c
ld a, (p2_count)
call print_two_digits
; Set P2 colour
ld a, FINAL_ROW
ld c, FINAL_P2_COL
ld b, 5
ld e, P2_TEXT
call set_attr_range
; Determine winner and display message
ld a, (p1_count)
ld b, a
ld a, (p2_count)
cp b
jr c, .sr_p1_wins ; p2 < p1, so p1 wins
jr z, .sr_draw ; p1 == p2, draw
; p2 > p1, p2 wins
jr .sr_p2_wins
.sr_p1_wins:
; Display "P1 WINS!"
ld b, WINNER_ROW
ld c, WINNER_COL
ld hl, msg_p1_wins
ld e, P1_TEXT
call print_message
; Calculate and show margin
ld a, (p1_count)
ld b, a
ld a, (p2_count)
neg
add a, b ; A = p1 - p2
call show_margin
jr .sr_prompt
.sr_p2_wins:
; Display "P2 WINS!"
ld b, WINNER_ROW
ld c, WINNER_COL
ld hl, msg_p2_wins
ld e, P2_TEXT
call print_message
; Calculate and show margin
ld a, (p2_count)
ld b, a
ld a, (p1_count)
neg
add a, b ; A = p2 - p1
call show_margin
jr .sr_prompt
.sr_draw:
; Display "DRAW!" (centred on winner row)
ld b, WINNER_ROW
ld c, WINNER_COL + 2
ld hl, msg_draw
ld e, TEXT_ATTR
call print_message
; No margin for draw - skip to prompt
.sr_prompt:
; Display "PRESS ANY KEY" prompt (on next row down)
ld b, WINNER_ROW + 2
ld c, CONTINUE_COL
ld hl, msg_continue
ld e, TEXT_ATTR
call print_message
ret
; ----------------------------------------------------------------------------
; Show Margin
; ----------------------------------------------------------------------------
; Displays "BY nn CELLS" for victory margin
; A = margin (difference in scores)
show_margin:
push af ; Save margin
; Print "BY "
ld b, MARGIN_ROW
ld c, MARGIN_COL
ld hl, msg_by
ld e, TEXT_ATTR
call print_message
; Print margin number
ld c, MARGIN_COL + 3
pop af
call print_two_digits
; Print " CELLS"
ld c, MARGIN_COL + 5
ld hl, msg_cells
call print_message
ret
; ----------------------------------------------------------------------------
; Print Message
; ----------------------------------------------------------------------------
; HL = pointer to null-terminated string
; B = row, C = starting column, E = attribute for message area
print_message:
; Save parameters we need later
push de ; Save attribute in E
push bc ; Save row (B) and start column (C)
; Print characters
.pm_loop:
ld a, (hl)
or a
jr z, .pm_done
call print_char
inc hl
inc c
jr .pm_loop
.pm_done:
; C now has end column
; Calculate length: end_col - start_col
ld a, c ; A = end column
pop bc ; B = row, C = start column
sub c ; A = length
ld d, a ; D = length (save it)
; Set up for set_attr_range: A=row, C=start_col, B=count, E=attr
ld a, b ; A = row
ld b, d ; B = count (length)
pop de ; E = attribute
call set_attr_range
ret
; ----------------------------------------------------------------------------
; Victory Celebration
; ----------------------------------------------------------------------------
; Flashes border in winner's colour
victory_celebration:
; Determine winner's border colour
ld a, (p1_count)
ld b, a
ld a, (p2_count)
cp b
jr c, .vc_p1 ; p2 < p1
jr z, .vc_draw ; draw - use white
ld d, P2_BORDER ; p2 wins
jr .vc_flash
.vc_p1:
ld d, P1_BORDER
jr .vc_flash
.vc_draw:
ld d, 7 ; White for draw
.vc_flash:
; Flash border 5 times
ld b, 5
.vc_loop:
push bc
; Winner's colour
ld a, d
out (KEY_PORT), a
; Delay
ld bc, 15000
.vc_delay1:
dec bc
ld a, b
or c
jr nz, .vc_delay1
; Black
xor a
out (KEY_PORT), a
; Delay
ld bc, 10000
.vc_delay2:
dec bc
ld a, b
or c
jr nz, .vc_delay2
pop bc
djnz .vc_loop
ret
; ----------------------------------------------------------------------------
; Draw Title Screen
; ----------------------------------------------------------------------------
; Displays game title and prompt
draw_title_screen:
; Draw "INK WAR" title
ld b, TITLE_ROW
ld c, TITLE_COL
ld hl, msg_title
ld e, TEXT_ATTR
call print_message
; Draw "1 - TWO PLAYER"
ld b, MODE1_ROW
ld c, MODE1_COL
ld hl, msg_mode1
ld e, TEXT_ATTR
call print_message
; Draw "2 - AI EASY"
ld b, MODE2_ROW
ld c, MODE2_COL
ld hl, msg_mode2
ld e, TEXT_ATTR
call print_message
; Draw "3 - AI MEDIUM"
ld b, MODE3_ROW
ld c, MODE3_COL
ld hl, msg_mode3
ld e, TEXT_ATTR
call print_message
; Draw "4 - AI HARD"
ld b, MODE4_ROW
ld c, MODE4_COL
ld hl, msg_mode4
ld e, TEXT_ATTR
call print_message
ret
; ----------------------------------------------------------------------------
; Wait Key Release
; ----------------------------------------------------------------------------
; Waits until all keys are released
wait_key_release:
.wkr_loop:
xor a
in a, (KEY_PORT)
cpl ; Invert (keys are active low)
and %00011111 ; Mask to key bits
jr nz, .wkr_loop ; Still holding a key
ret
; ----------------------------------------------------------------------------
; Wait For Key
; ----------------------------------------------------------------------------
; Waits until any key is pressed
wait_for_key:
; First wait for all keys to be released
.wfk_release:
xor a
in a, (KEY_PORT)
cpl ; Invert (keys are active low)
and %00011111 ; Mask to key bits
jr nz, .wfk_release
; Now wait for a key press
.wfk_wait:
halt ; Wait for interrupt
xor a
in a, (KEY_PORT)
cpl
and %00011111
jr z, .wfk_wait
ret
; ----------------------------------------------------------------------------
; AI Make Move
; ----------------------------------------------------------------------------
; AI picks a cell based on difficulty level
ai_make_move:
; Dispatch based on difficulty
ld a, (ai_difficulty)
or a
jr z, .aim_easy ; AI_EASY = 0
cp AI_MEDIUM
jr z, .aim_medium
; AI_HARD - full strategy
call find_best_adjacent_cell
jr .aim_have_cell
.aim_easy:
; Random moves
call find_random_empty_cell
jr .aim_have_cell
.aim_medium:
; Adjacent priority only (no defense/position)
call find_adjacent_only
; Fall through to .aim_have_cell
.aim_have_cell:
; A = cell index (0-63), or $FF if board full
cp $ff
ret z ; No empty cells (shouldn't happen)
; Convert index to row/col and set cursor
ld b, a
and %00000111 ; Column = index AND 7
ld (cursor_col), a
ld a, b
rrca
rrca
rrca
and %00000111 ; Row = index >> 3
ld (cursor_row), a
; Claim the cell (reuse existing code)
call claim_cell
call sound_claim
; Switch player
ld a, (current_player)
xor 3
ld (current_player), a
call draw_ui
; Check if game is over
call check_game_over
or a
jr z, .aim_continue
; Game over - play appropriate sound and show results
call play_result_sound
call show_results
call victory_celebration
call wait_for_key
; Return to title screen
ld a, GS_TITLE
ld (game_state), a
call init_screen
call draw_title_screen
xor a
out (KEY_PORT), a ; Black border for title
ret
.aim_continue:
call update_border
call draw_cursor
ret
; ----------------------------------------------------------------------------
; Find Best Cell (Offense + Defense + Position)
; ----------------------------------------------------------------------------
; Returns A = index of empty cell with best combined score, or $FF if none
; Score = adjacent AI + adjacent human + position bonus (corner=2, edge=1)
; This makes the AI value strategic positions in addition to adjacency
find_best_adjacent_cell:
; Initialize best tracking
ld a, $ff
ld (best_cell), a ; No best cell yet
xor a
ld (best_score), a ; Best score = 0
; Scan all 64 cells
ld c, 0 ; C = current cell index
.fbac_loop:
; Check if cell is empty
ld hl, board_state
ld d, 0
ld e, c
add hl, de
ld a, (hl)
or a
jr nz, .fbac_next ; Not empty, skip
; Empty cell - count adjacent AI cells (offense)
push bc
ld a, c
call count_adjacent_ai
ld b, a ; B = AI adjacent count
; Count adjacent human cells (defense)
ld a, c
call count_adjacent_p1
add a, b ; A = adjacency score
ld b, a ; B = adjacency score
; Add position bonus (corners=2, edges=1)
ld a, c
call get_position_bonus
add a, b ; A = total score
pop bc
; Compare with best score
ld b, a ; B = this score
ld a, (best_score)
cp b
jr nc, .fbac_next ; Current best >= this score
; New best found
ld a, b
ld (best_score), a
ld a, c
ld (best_cell), a
.fbac_next:
inc c
ld a, c
cp 64
jr c, .fbac_loop ; Continue if c < 64
; Check if we found a good cell
ld a, (best_score)
or a
jr z, .fbac_random ; No scored cells, use random
; Return best cell
ld a, (best_cell)
ret
.fbac_random:
; Fall back to random empty cell
call find_random_empty_cell
ret
best_cell: defb 0
best_score: defb 0
; ----------------------------------------------------------------------------
; Find Adjacent Only (Medium Difficulty)
; ----------------------------------------------------------------------------
; Returns A = index of empty cell with most AI neighbors, or $FF if none
; Only considers AI adjacency - no defense or position bonus
find_adjacent_only:
; Initialize best tracking
ld a, $ff
ld (best_cell), a
xor a
ld (best_score), a
; Scan all 64 cells
ld c, 0
.fao_loop:
; Check if cell is empty
ld hl, board_state
ld d, 0
ld e, c
add hl, de
ld a, (hl)
or a
jr nz, .fao_next
; Empty cell - count adjacent AI cells only
push bc
ld a, c
call count_adjacent_ai
pop bc
; Compare with best score
ld b, a
ld a, (best_score)
cp b
jr nc, .fao_next
; New best found
ld a, b
ld (best_score), a
ld a, c
ld (best_cell), a
.fao_next:
inc c
ld a, c
cp 64
jr c, .fao_loop
; Check if we found an adjacent cell
ld a, (best_score)
or a
jr z, .fao_random
; Return best adjacent cell
ld a, (best_cell)
ret
.fao_random:
; Fall back to random empty cell
call find_random_empty_cell
ret
; ----------------------------------------------------------------------------
; Get Position Bonus
; ----------------------------------------------------------------------------
; A = cell index (0-63)
; Returns A = position bonus (corner=2, edge=1, center=0)
get_position_bonus:
; Get row and column from index
ld b, a
and %00000111 ; Column (0-7)
ld c, a
ld a, b
rrca
rrca
rrca
and %00000111 ; Row (0-7)
ld b, a ; B = row, C = col
; Check for corner (row=0 or 7, col=0 or 7)
ld a, b
or a
jr z, .gpb_row_edge ; Row 0
cp 7
jr z, .gpb_row_edge ; Row 7
; Row is not edge
ld a, c
or a
jr z, .gpb_edge ; Col 0, row not edge = edge
cp 7
jr z, .gpb_edge ; Col 7, row not edge = edge
; Neither row nor col is edge = center
xor a ; Return 0
ret
.gpb_row_edge:
; Row is 0 or 7, check column
ld a, c
or a
jr z, .gpb_corner ; Col 0 = corner
cp 7
jr z, .gpb_corner ; Col 7 = corner
; Row edge but not corner
jr .gpb_edge
.gpb_corner:
ld a, 2 ; Corner bonus
ret
.gpb_edge:
ld a, 1 ; Edge bonus
ret
; ----------------------------------------------------------------------------
; Count Adjacent AI Cells
; ----------------------------------------------------------------------------
; A = cell index (0-63)
; Returns A = count of adjacent cells owned by AI (P2)
count_adjacent_ai:
ld (temp_cell), a
xor a
ld (adj_count), a
; Get row and column
ld a, (temp_cell)
ld b, a
and %00000111 ; Column
ld c, a
ld a, b
rrca
rrca
rrca
and %00000111 ; Row
ld b, a ; B = row, C = col
; Check up (row-1)
ld a, b
or a
jr z, .caa_skip_up ; Row 0, no up neighbor
dec a ; Row - 1
push bc
ld b, a
call .caa_check_cell
pop bc
.caa_skip_up:
; Check down (row+1)
ld a, b
cp 7
jr z, .caa_skip_down ; Row 7, no down neighbor
inc a ; Row + 1
push bc
ld b, a
call .caa_check_cell
pop bc
.caa_skip_down:
; Check left (col-1)
ld a, c
or a
jr z, .caa_skip_left ; Col 0, no left neighbor
dec a ; Col - 1
push bc
ld c, a
call .caa_check_cell
pop bc
.caa_skip_left:
; Check right (col+1)
ld a, c
cp 7
jr z, .caa_skip_right ; Col 7, no right neighbor
inc a ; Col + 1
push bc
ld c, a
call .caa_check_cell
pop bc
.caa_skip_right:
ld a, (adj_count)
ret
; Helper: check if cell at (B,C) is AI owned
.caa_check_cell:
; Calculate index: row*8 + col
ld a, b
rlca
rlca
rlca ; Row * 8
add a, c ; + col
ld hl, board_state
ld d, 0
ld e, a
add hl, de
ld a, (hl)
cp STATE_P2 ; AI is Player 2
ret nz ; Not AI cell
; AI cell - increment count
ld a, (adj_count)
inc a
ld (adj_count), a
ret
temp_cell: defb 0
adj_count: defb 0
; ----------------------------------------------------------------------------
; Count Adjacent Human Cells
; ----------------------------------------------------------------------------
; A = cell index (0-63)
; Returns A = count of adjacent cells owned by human (P1)
count_adjacent_p1:
ld (temp_cell), a
xor a
ld (adj_count), a
; Get row and column
ld a, (temp_cell)
ld b, a
and %00000111 ; Column
ld c, a
ld a, b
rrca
rrca
rrca
and %00000111 ; Row
ld b, a ; B = row, C = col
; Check up (row-1)
ld a, b
or a
jr z, .cap_skip_up ; Row 0, no up neighbor
dec a ; Row - 1
push bc
ld b, a
call .cap_check_cell
pop bc
.cap_skip_up:
; Check down (row+1)
ld a, b
cp 7
jr z, .cap_skip_down ; Row 7, no down neighbor
inc a ; Row + 1
push bc
ld b, a
call .cap_check_cell
pop bc
.cap_skip_down:
; Check left (col-1)
ld a, c
or a
jr z, .cap_skip_left ; Col 0, no left neighbor
dec a ; Col - 1
push bc
ld c, a
call .cap_check_cell
pop bc
.cap_skip_left:
; Check right (col+1)
ld a, c
cp 7
jr z, .cap_skip_right ; Col 7, no right neighbor
inc a ; Col + 1
push bc
ld c, a
call .cap_check_cell
pop bc
.cap_skip_right:
ld a, (adj_count)
ret
; Helper: check if cell at (B,C) is human owned
.cap_check_cell:
; Calculate index: row*8 + col
ld a, b
rlca
rlca
rlca ; Row * 8
add a, c ; + col
ld hl, board_state
ld d, 0
ld e, a
add hl, de
ld a, (hl)
cp STATE_P1 ; Human is Player 1
ret nz ; Not human cell
; Human cell - increment count
ld a, (adj_count)
inc a
ld (adj_count), a
ret
; ----------------------------------------------------------------------------
; Find Random Empty Cell
; ----------------------------------------------------------------------------
; Returns A = index of a random empty cell (0-63), or $FF if none
find_random_empty_cell:
; Get random starting position
call get_random
and %00111111 ; Limit to 0-63
ld c, a ; C = start index
ld b, 64 ; B = cells to check
.frec_loop:
; Check if cell at index C is empty
ld hl, board_state
ld d, 0
ld e, c
add hl, de
ld a, (hl)
or a
jr z, .frec_found ; Found empty cell
; Try next cell (wrap around)
inc c
ld a, c
and %00111111 ; Wrap at 64
ld c, a
djnz .frec_loop
; No empty cells found
ld a, $ff
ret
.frec_found:
ld a, c ; Return cell index
ret
; ----------------------------------------------------------------------------
; Get Random
; ----------------------------------------------------------------------------
; Returns A = pseudo-random number using R register
get_random:
ld a, r ; R register changes every instruction
ld b, a
ld a, (random_seed)
add a, b
rlca
xor b
ld (random_seed), a
ret
random_seed: defb $5a ; Seed value
; ----------------------------------------------------------------------------
; Messages
; ----------------------------------------------------------------------------
msg_p1_wins: defb "P1 WINS!", 0
msg_p2_wins: defb "P2 WINS!", 0
msg_draw: defb "DRAW!", 0
msg_title: defb "INK WAR", 0
msg_mode1: defb "1 - TWO PLAYER", 0
msg_mode2: defb "2 - AI EASY", 0
msg_mode3: defb "3 - AI MEDIUM", 0
msg_mode4: defb "4 - AI HARD", 0
msg_continue: defb "PRESS ANY KEY", 0
msg_gameover: defb "GAME OVER", 0
msg_final: defb "FINAL SCORE", 0
msg_by: defb "BY ", 0
msg_cells: defb " CELLS", 0
; ----------------------------------------------------------------------------
; Variables
; ----------------------------------------------------------------------------
game_state: defb 0 ; 0=title, 1=playing, 2=results
game_mode: defb 0 ; 0=two player, 1=vs AI
ai_difficulty: defb 0 ; 0=easy, 1=medium, 2=hard
cursor_row: defb 0
cursor_col: defb 0
key_pressed: defb 0
last_key: defb 0 ; Previous frame's key for repeat detection
key_timer: defb 0 ; Countdown for key repeat delay
ai_timer: defb 0 ; Countdown before AI moves
current_player: defb 1
p1_count: defb 0
p2_count: defb 0
board_state: defs 64, 0
; ----------------------------------------------------------------------------
; End
; ----------------------------------------------------------------------------
end start
Try This: Percentage Display
Show victory as a percentage of the board:
; Calculate percentage: (score * 100) / 64
ld a, (p1_count)
; ... multiply by 100, divide by 64 ...
; Display as "50%" instead of "32"This gives players a different perspective on their performance.
Try This: Best Score Tracking
Track and display the highest winning margin:
best_margin: defb 0
; After calculating margin:
ld b, a ; B = current margin
ld a, (best_margin)
cp b
jr nc, .not_best
ld a, b
ld (best_margin), a ; New record
; ... display "NEW RECORD!" ...This adds replay value by giving players a target to beat.
What You’ve Learnt
- Screen composition — Building complex displays from simple elements
- Information hierarchy — Ordering content by importance
- Visual consistency — Maintaining colour coding throughout
- Calculation techniques — Using
negfor subtraction
What’s Next
In Unit 16, we’ll complete Phase 1 with final polish and a complete playable game.
What Changed
Unit 14 → Unit 15
+118-17
| 1 | 1 | ; ============================================================================ | |
| 2 | - | ; INK WAR - Unit 14: Sound Effects | |
| 2 | + | ; INK WAR - Unit 15: Results Screen | |
| 3 | 3 | ; ============================================================================ | |
| 4 | - | ; Complete audio feedback: menu select, claim, error, turn change, victory. | |
| 5 | - | ; The beeper gives every action a distinctive sound. | |
| 4 | + | ; Proper end-of-game display with final scores, winner announcement, | |
| 5 | + | ; and score difference. Clear presentation of the game outcome. | |
| 6 | 6 | ; | |
| 7 | 7 | ; Controls: Q=Up, A=Down, O=Left, P=Right, SPACE=Claim | |
| 8 | 8 | ; 1=Two Player, 2=AI Easy, 3=AI Medium, 4=AI Hard | |
| ... | |||
| 95 | 95 | MODE4_COL equ 10 | |
| 96 | 96 | | |
| 97 | 97 | ; Results screen positions | |
| 98 | + | GAMEOVER_ROW equ 18 ; "GAME OVER" header | |
| 99 | + | GAMEOVER_COL equ 11 ; (32-9)/2 = 11.5 | |
| 100 | + | FINAL_ROW equ 20 ; Final score row | |
| 101 | + | FINAL_P1_COL equ 8 ; "P1: nn" | |
| 102 | + | FINAL_P2_COL equ 20 ; "P2: nn" | |
| 103 | + | WINNER_ROW equ 22 ; Winner announcement | |
| 104 | + | WINNER_COL equ 10 ; Centred | |
| 105 | + | MARGIN_ROW equ 23 ; "BY nn CELLS" | |
| 106 | + | MARGIN_COL equ 11 | |
| 98 | 107 | CONTINUE_ROW equ 22 ; "PRESS ANY KEY" after results | |
| 99 | 108 | CONTINUE_COL equ 9 ; (32-13)/2 = 9.5 | |
| 100 | 109 | | |
| ... | |||
| 1387 | 1396 | ; ---------------------------------------------------------------------------- | |
| 1388 | 1397 | ; Show Results | |
| 1389 | 1398 | ; ---------------------------------------------------------------------------- | |
| 1390 | - | ; Displays winner message based on scores | |
| 1399 | + | ; Displays enhanced results screen with final scores and winner | |
| 1391 | 1400 | | |
| 1392 | 1401 | show_results: | |
| 1393 | 1402 | ; Clear turn indicator | |
| ... | |||
| 1397 | 1406 | ld e, TEXT_ATTR | |
| 1398 | 1407 | call set_attr_range | |
| 1399 | 1408 | | |
| 1400 | - | ; Determine winner | |
| 1409 | + | ; Display "GAME OVER" header | |
| 1410 | + | ld b, GAMEOVER_ROW | |
| 1411 | + | ld c, GAMEOVER_COL | |
| 1412 | + | ld hl, msg_gameover | |
| 1413 | + | ld e, TEXT_ATTR | |
| 1414 | + | call print_message | |
| 1415 | + | | |
| 1416 | + | ; Display final P1 score | |
| 1417 | + | ld b, FINAL_ROW | |
| 1418 | + | ld c, FINAL_P1_COL | |
| 1419 | + | ld a, 'P' | |
| 1420 | + | call print_char | |
| 1421 | + | inc c | |
| 1422 | + | ld a, '1' | |
| 1423 | + | call print_char | |
| 1424 | + | inc c | |
| 1425 | + | ld a, ':' | |
| 1426 | + | call print_char | |
| 1427 | + | inc c | |
| 1428 | + | ld a, (p1_count) | |
| 1429 | + | call print_two_digits | |
| 1430 | + | ; Set P1 colour | |
| 1431 | + | ld a, FINAL_ROW | |
| 1432 | + | ld c, FINAL_P1_COL | |
| 1433 | + | ld b, 5 | |
| 1434 | + | ld e, P1_TEXT | |
| 1435 | + | call set_attr_range | |
| 1436 | + | | |
| 1437 | + | ; Display final P2 score | |
| 1438 | + | ld b, FINAL_ROW | |
| 1439 | + | ld c, FINAL_P2_COL | |
| 1440 | + | ld a, 'P' | |
| 1441 | + | call print_char | |
| 1442 | + | inc c | |
| 1443 | + | ld a, '2' | |
| 1444 | + | call print_char | |
| 1445 | + | inc c | |
| 1446 | + | ld a, ':' | |
| 1447 | + | call print_char | |
| 1448 | + | inc c | |
| 1449 | + | ld a, (p2_count) | |
| 1450 | + | call print_two_digits | |
| 1451 | + | ; Set P2 colour | |
| 1452 | + | ld a, FINAL_ROW | |
| 1453 | + | ld c, FINAL_P2_COL | |
| 1454 | + | ld b, 5 | |
| 1455 | + | ld e, P2_TEXT | |
| 1456 | + | call set_attr_range | |
| 1457 | + | | |
| 1458 | + | ; Determine winner and display message | |
| 1401 | 1459 | ld a, (p1_count) | |
| 1402 | 1460 | ld b, a | |
| 1403 | 1461 | ld a, (p2_count) | |
| ... | |||
| 1409 | 1467 | | |
| 1410 | 1468 | .sr_p1_wins: | |
| 1411 | 1469 | ; Display "P1 WINS!" | |
| 1412 | - | ld b, RESULT_ROW | |
| 1413 | - | ld c, RESULT_COL | |
| 1470 | + | ld b, WINNER_ROW | |
| 1471 | + | ld c, WINNER_COL | |
| 1414 | 1472 | ld hl, msg_p1_wins | |
| 1415 | 1473 | ld e, P1_TEXT | |
| 1416 | 1474 | call print_message | |
| 1417 | - | jr .sr_continue | |
| 1475 | + | ; Calculate and show margin | |
| 1476 | + | ld a, (p1_count) | |
| 1477 | + | ld b, a | |
| 1478 | + | ld a, (p2_count) | |
| 1479 | + | neg | |
| 1480 | + | add a, b ; A = p1 - p2 | |
| 1481 | + | call show_margin | |
| 1482 | + | jr .sr_prompt | |
| 1418 | 1483 | | |
| 1419 | 1484 | .sr_p2_wins: | |
| 1420 | 1485 | ; Display "P2 WINS!" | |
| 1421 | - | ld b, RESULT_ROW | |
| 1422 | - | ld c, RESULT_COL | |
| 1486 | + | ld b, WINNER_ROW | |
| 1487 | + | ld c, WINNER_COL | |
| 1423 | 1488 | ld hl, msg_p2_wins | |
| 1424 | 1489 | ld e, P2_TEXT | |
| 1425 | 1490 | call print_message | |
| 1426 | - | jr .sr_continue | |
| 1491 | + | ; Calculate and show margin | |
| 1492 | + | ld a, (p2_count) | |
| 1493 | + | ld b, a | |
| 1494 | + | ld a, (p1_count) | |
| 1495 | + | neg | |
| 1496 | + | add a, b ; A = p2 - p1 | |
| 1497 | + | call show_margin | |
| 1498 | + | jr .sr_prompt | |
| 1427 | 1499 | | |
| 1428 | 1500 | .sr_draw: | |
| 1429 | - | ; Display "DRAW!" | |
| 1430 | - | ld b, RESULT_ROW | |
| 1431 | - | ld c, RESULT_COL + 2 ; Centre "DRAW!" better | |
| 1501 | + | ; Display "DRAW!" (centred on winner row) | |
| 1502 | + | ld b, WINNER_ROW | |
| 1503 | + | ld c, WINNER_COL + 2 | |
| 1432 | 1504 | ld hl, msg_draw | |
| 1433 | 1505 | ld e, TEXT_ATTR | |
| 1434 | 1506 | call print_message | |
| 1507 | + | ; No margin for draw - skip to prompt | |
| 1435 | 1508 | | |
| 1436 | - | .sr_continue: | |
| 1437 | - | ; Display "PRESS ANY KEY" prompt | |
| 1438 | - | ld b, CONTINUE_ROW | |
| 1509 | + | .sr_prompt: | |
| 1510 | + | ; Display "PRESS ANY KEY" prompt (on next row down) | |
| 1511 | + | ld b, WINNER_ROW + 2 | |
| 1439 | 1512 | ld c, CONTINUE_COL | |
| 1440 | 1513 | ld hl, msg_continue | |
| 1514 | + | ld e, TEXT_ATTR | |
| 1515 | + | call print_message | |
| 1516 | + | ret | |
| 1517 | + | | |
| 1518 | + | ; ---------------------------------------------------------------------------- | |
| 1519 | + | ; Show Margin | |
| 1520 | + | ; ---------------------------------------------------------------------------- | |
| 1521 | + | ; Displays "BY nn CELLS" for victory margin | |
| 1522 | + | ; A = margin (difference in scores) | |
| 1523 | + | | |
| 1524 | + | show_margin: | |
| 1525 | + | push af ; Save margin | |
| 1526 | + | ; Print "BY " | |
| 1527 | + | ld b, MARGIN_ROW | |
| 1528 | + | ld c, MARGIN_COL | |
| 1529 | + | ld hl, msg_by | |
| 1441 | 1530 | ld e, TEXT_ATTR | |
| 1531 | + | call print_message | |
| 1532 | + | ; Print margin number | |
| 1533 | + | ld c, MARGIN_COL + 3 | |
| 1534 | + | pop af | |
| 1535 | + | call print_two_digits | |
| 1536 | + | ; Print " CELLS" | |
| 1537 | + | ld c, MARGIN_COL + 5 | |
| 1538 | + | ld hl, msg_cells | |
| 1442 | 1539 | call print_message | |
| 1443 | 1540 | ret | |
| 1444 | 1541 | | |
| ... | |||
| 2147 | 2244 | msg_mode3: defb "3 - AI MEDIUM", 0 | |
| 2148 | 2245 | msg_mode4: defb "4 - AI HARD", 0 | |
| 2149 | 2246 | msg_continue: defb "PRESS ANY KEY", 0 | |
| 2247 | + | msg_gameover: defb "GAME OVER", 0 | |
| 2248 | + | msg_final: defb "FINAL SCORE", 0 | |
| 2249 | + | msg_by: defb "BY ", 0 | |
| 2250 | + | msg_cells: defb " CELLS", 0 | |
| 2150 | 2251 | | |
| 2151 | 2252 | ; ---------------------------------------------------------------------------- | |
| 2152 | 2253 | ; Variables |
